Starter Pack


Voxel’s first module pack: a powerful smart home controller and smart plug, open-sourced.

Augment your smart home with handy environment sensors, brilliant dot matrix displays and tactile inputs. Compatible with most of your favourite devices.

Brain Module

Brain Smart Plug Module

Environment Module

Motion Module

Multi-input Module








Designed for Makers, by Makers

We believe smart homes should be a joy to work with and maker tech should be easy to get up and running. Our new open smart home controller is built on principles of freedom, transparency and privacy.

Privacy >



Idea to Invention in Record Time

Don't let wiring, compatability or drivers get in the way of creativity. Magnetic modularity allows you to make, break, rebuild, combine, mix, match and repeat.



Code Your Way

An intuitive custom coding interface for beginners lets you create quick projects based on Blockly by Google. Supports Python and C++ for everything above.













Endless Possibilities

Download creations for your modules from a huge selection on the community Hub. All completely free and open source. Modify and customise, then share your new creation with just one click.





Completely Hackable

Proudly open source. Yours to hack, tinker and upgrade. So modular that it arrives dissasembled: the ESP-8266 chip and dot-matrix display are yours to integrate into anything.






Tech specs


Software

Program with custom Voxel Block Code,or
code in Python or C++.

  • Programmable over USB type-C with
    Windows, Mac and Linux
  • ESP-8266 functionality available
    as normal
  • Code straight in Arduino IDE

Integrates with top Smart Home platforms

  • Google Home / Alexa / HomeKit
  • IFTTT / Tasmota / Home Assistant /
    OpenHAB / MQTT

Brain Module

Measurements
  • 60mm x 60mm x 60mm, 45g
Connectivity
  • 3 x Magic Magnetic Voxel I2C connectors
  • USB Type-C PD

ESP-8266 WiFi microcontroller

  • 4mb of flash / 80 MHz clock speed
  • 11 x GPIO pins / 1 x Analog input ADC pin
  • Hardware SPI, UART and I2C

Vibrant 16 x 16 LED dot-matrix display with SPI


Brain Smart Plug Module

Measurements
  • 60mm x 60mm x 88mm, 60g
Connectivity
  • 1 x Magic Magnetic Voxel I2C connector

ESP-8266 WiFi microcontroller

  • 4mb of flash / 80 MHz clock speed
  • Pins not accessible - shock risk!

13A Relay / Reprogrammable tactile button


Environment Module

Measurements
  • 60mm x 60mm x 15mm, 12g

DHT22 Temperature and Humidity Sensor

MAX44009 Ambient Light Sensor

Connectivity
  • 2 x Magic Magnetic Voxel I2C
    connectors

Multi Input Module

Measurements
  • 60mm x 60mm x 20mm, 15g

Rotary Encoder

3 x Tactile Buttons

Connectivity
  • 1 x Magic Magnetic Voxel I2C connectors

Environment Module

Measurements
  • 60mm x 60mm x 15mm, 12g

DHT22 Temperature and Humidity Sensor

MAX44009 Ambient Light Sensor

Connectivity
  • 2 x Magic Magnetic Voxel I2C connectors





FAQs

Voxel uses I2C to connect sensors and inputs and is able to subscribe to MQTT topics. It can also emulate some smart home products to allow control through Alexa or Google Home

We intend to release a battery pack that is compatible with our Voxel connectors as soon as possible. In the meantime Voxels can be powered through any power bank over USB.

We are focusing on providing quality hardware as well as open source software, wheras Home Assistant and OpenHAB both focus purely on software.

We will pay full-time developers to contribute to our source code.






Upcoming releases

Starter Pack

  • Brain + dot-matrix display
  • Brain + smart plug
  • Temperature + humidity + ambient light
  • Motion and gesture sensor

Buy >
Smart Plug Pack

3 x Voxel Brain Smart plugs with Magic Magnetic I2C connectors.

Buy >
Naked Brain

Just the PCBs and connectors. For integration into anything you can imagine.

Buy >
Voice Assistant Pack

Microphone and speaker with Google Assistant, Alexa and Mycroft voice assistant functionality.

Coming soon

Wireless Connection Pack

Small form-factor brain and battery modules to be placed anywhere around the house.

Coming soon

Retro Gaming Pack

Fun retro gaming style gaming inputs, joystick and 4 tactile buttons.

Coming soon



We need you!

Help us decide what to develop next. We're working alongide our community to design the next releases. Have your say:

Join forum



Why Voxel?

Complete freedom to create

Build whatever you can dream up. Completely open source and customisable.

Tutorials >

Built with privacy first

Our business model is about selling great hardware, not your data. Find out more about us:

About us >

Join a growing movement

Get ideas and support from the wonderful Voxel community. Share your creations with 1 click.

Voxel Hub >
